PFH-SPC-21-30-4F-GP-ML : SPECTRUM INOX Premier Filter Housing 21 X 30" 4" with Gauge Ports 1575 LPM*
PFH-SPC-21-30-4F-GP-ML : SPECTRUM INOX Premier Filter Housing 21 X ...
Product Description
* Flow rate based on 20 micron SPE pleated filter.
Taking flow capacities to over 172 m³ per hour with 6" piping relies on equipment that is not only durable, but designed to aid ease of use.
The two larger SPECTRUM Inox versions come as standard with heavy-duty mounting legs for housing security and a swing bolt and davit arm configuration for quick, easy and safe cartridge changeout.
The big brothers to the 3, 5, 7 and 12 round housings, these larger sizes use 4" DN100 or 6" DN150 flanges as standard to accommodate, with minimal pressure loss, flows of up to 2,800 lpm. The top plate in these sizes has multiple tie rod threads, hold down plates and springs to evenly spread compression. This arrangement allows up to a 1" cartridge length variation and makes changeout easy.
PN16 BS EN1092-1 flanges are standard. Drains are ½" on 22 round and ¾" on 36 Housings are suitable for DOE, 222 or 2 ¾ " OD style cartridges and come pre configured with 2 x ¼ " gauge ports and 2 x 1" drain ports.
Maximum Pressure: 10 bar
Maximum Temperature: 120°C
Key product features
•PED compliant and DWI approved
•PFH large multi-round housings with 4" or 6" flanges achieve flow capacities over 4100 lpm with minimal pressure loss
•Manufactured with heavy duty mounting legs which bolt to the floor for added security
•Swing bolt and davit arm head configuration for quick, easy and safe cartridge change-out
•Feature a top plate with tie rod threads to evenly spread compression over the spring seals making change-out easy.
•An optional universal housing adaptor will securely hold 222 and DOE cartridges
•Drains are 1/2" on 22 round and 3/4" on 36 and 52 round housings.
•The 22,36 and 52 round accept cartridges with an outer diameter of up to 2 5/8". For 2 3/4" diameter cartridges, change coding to 21,32 and 50 respectively.
Features & Information
•High Temperature installations
•High Pressure applications
•Industrial applications
•High flow capacity applications
An extensive selection of options and spares are available upon request.
