Multi Media Filter with Fleck Valve (0.6 to 10.7 m³/hr)
Multi Media Filter with Fleck Valve (0.6 to 10.7 m³/hr)
Multi Media Filter with Fleck Valve (0.6 to 10.7 m³/hr)
The Multi Media Filter with Fleck Valve is a highly efficient and durable solution for water filtration. Designed to handle flow rates from 0.6 to 10.7 m³/hr, it is suitable for residential, commercial, and industrial applications where water quality and performance are essential.
Key Features
-
Wide Flow Rate Range
Accommodates varying water filtration needs with a service flow rate from 0.6 to 10.7 m³/hr. -
Efficient Backwashing
Backwash flow rates range from 1.2 to 22.3 m³/hr, ensuring optimal media cleaning and extended filter performance. -
Durable Vessel Options
Available in diameters from 10” to 42” to suit diverse capacities and operating conditions. -
Advanced Media Composition
Features multi-layered filtration using anthracite (0.8–1.25mm), filter sand (3–5mm), and support gravel for effective removal of impurities. -
Programmable Regeneration
Integrated Fleck Valve provides manual and programmable settings for tailored operation, improving efficiency and flexibility.
Operational Specifications
-
Electrical Requirements
Operates on 230-24V, 50 Hz power with a 55-watt rating. -
Pressure and Temperature Ratings
Functions within an inlet pressure range of 2 to 7 Bar and can handle water temperatures up to 43°C. -
Compact and Flexible Installation
Features BSP inlet/outlet connections ranging from 1” to 2” with low average pressure loss of 1 Bar.
Model Options and Dimensions
| Model Reference | Valve H1 (mm) | Vessel H2 (mm) | Vessel B1 (mm) | Filter HT (mm) | Connection (BSP) |
|---|---|---|---|---|---|
| FLF58SXTC10MM | 220 | 1387 | 257 | 1607 | 1” |
| FLF58SXTC13MM | 220 | 1374 | 334 | 1594 | 1” |
| FLF58SXTC14MM | 220 | 1660 | 369 | 1880 | 1” |
| FLF58SXTC16MM | 220 | 1660 | 406 | 1880 | 1” |
| FLF27SXTC18MM | 220 | 1750 | 469 | 1970 | 1” |
| FLF28SXTC21MM | 220 | 1640 | 552 | 1860 | 1½” |
| FLF31SXTC24MM | 200 | 2230 | 610 | 2430 | 2” |
| FLF31SXTC30MM | 200 | 2300 | 770 | 2500 | 2” |
| FLF31NXTC36MM | 200 | 2350 | 927 | 2550 | 2” |
| FLF31NXTC42MM | 200 | 2435 | 1074 | 2635 | 2” |
Performance Table
| Vessel Diameter | Service Flow Rate (m³/hr) | Backwash Flow Rate (m³/hr) |
|---|---|---|
| 10” | 0.6 | 1.2 |
| 13” | 1.1 | 2.0 |
| 14” | 1.2 | 2.4 |
| 16” | 1.5 | 3.2 |
| 18” | 1.9 | 4.1 |
| 21” | 2.6 | 5.2 |
| 24” | 3.5 | 7.3 |
| 30” | 5.4 | 11.4 |
| 36” | 7.8 | 16.4 |
| 42” | 10.7 | 22.3 |
Why Choose This Multi Media Filter?
The Fleck Valve Multi Media Filter is designed to meet your water filtration needs with unmatched efficiency and reliability. Its robust construction, advanced filtration media, and programmable operations make it a top choice for water treatment systems.
Get yours today and ensure high-quality water filtration for every application!
