AquaMatic K524-UF08UEP 2inch Female Adaptor Pair 1070256

AquaMatic K524-UF08UEP 2" PVC Female Socket Adaptor Kit (Pair) – Part No: 1070256

The AquaMatic K524-UF08UEP 2" Female Adaptor Kit (Part No: 1070256) is a genuine OEM commercial pipework connection solution engineered specifically for AquaMatic K52 Series 2-inch composite control valves.

This premium installation kit includes a pair of high-purity PVC female socket adapters matching the ASTM 2" standard. Designed to thread directly onto the male ports of the valve body, these adapters eliminate the need for secondary split retaining rings or separate union nuts. They provide a robust, streamlined transition, allowing standard 2-inch PVC pressure pipes to be cleanly solvent-welded into place for commercial and industrial fluid control applications.

Key Features & Benefits

• Direct Valve Body Integration: Engineered by AquaMatic to thread straight onto the 2" K524 series valve ports, ensuring a compact, secure mechanical link without extra clamping hardware.

• Premium EPDM O-Rings Included: Supplied with factory-spec, industrial-grade EPDM O-rings to create an immediate, pressure-tight compression seal upon tightening.

• Rigid PVC Construction: Offers exceptional resistance to scale build-up, corrosion, and aggressive water treatment chemistries, ensuring long-term system integrity.

• Precision ASTM 2" Socket Ends: Precision-molded female sockets ensure a tight, reliable solvent-weld bond with standard 2-inch PVC pipework using standard solvent cement.

• Packaged as a Pair: Contains two female adapters and two EPDM O-rings to completely outfit both the inlet and outlet ports of a single valve assembly.

Dimensions:

Technical Specifications

• Manufacturer: AquaMatic (AQ Matic)

• Part Number: 1070256

• Model Code: K524-UF08UEP

• Size: 2" (2 Inch)

• Connection Type: Threaded Female End (Valve Side) x Female Socket Weld / Slip (Pipe Side)

• Pipe Standard: ASTM (American Standard)

• Material: Rigid PVC (Polyvinyl Chloride)

• Seal Material: EPDM (Ethylene Propylene Diene Monomer)

• Package Quantity: 1 Kit (Includes 2 x Threaded Female Adaptors & 2 x EPDM O-rings)

• Compatible Valves: AquaMatic K52 Series 2" Composite Valves

Typical Applications

• Large-scale commercial water softeners and iron filtration systems

• Industrial Reverse Osmosis (RO) system plumbing manifolds

• Multi-media, carbon, and sand filter setups

• Deionisation (DI) and demineralisation exchange plants

• High-volume process water management loops
