What is the SPECTRUM Economic Three Stage Housing System 10inch used for?

The SPECTRum Economic Three-Stage Housing System is a pre-assembled, space-saving water filtration system designed for residential, commercial, and light industrial use. By combining three filters into one unit, it provides multi-stage water treatment without needing to plumb multiple housings together. Here’s how it's typically used and configured: Progressive Multi-Stage Filtration The system cleans water in stages, tackling different contaminants at each step. A common setup includes: Stage 1 (Pre-Filtration): A sediment filter (e.g., 50 to 5 microns) traps sand, rust, scale, and other large particles. Stage 2 (Chemical Treatment): A carbon cartridge reduces chlorine, volatile organic compounds (VOCs), bad tastes, and odours. Stage 3 (Final Filtration): A fine sediment filter (e.g., 1 micron), a specialized resin cartridge (for deionisation or scale), or a microbiological barrier provides the final polish. Protecting Downstream Systems This three-stage setup is effective at extending the life of more delicate or expensive filters (like UV sterilizers or reverse osmosis systems) by removing clogging sediments and damaging chlorine first. Treating Private Water Supplies It is often used for private water sources like boreholes, wells, or springs. These sources often require robust, multi-stage treatment (e.g., sediment removal followed by iron reduction) before the water is used. Key System Specifications Cartridge Compatibility: Fits standard 10-inch double open-ended (DOE) cartridges. Port Configurations: Available in multiple port sizes (¼” to ¾” BSP) to match different flow rates and pipes. Pressure & Temperature: Rated for pressures up to 8.6 bar (polypropylene) or 6.9 bar (clear styrene) and operates safely between 4°C and 40°C. Installation Readiness: Includes a mounting bracket, sump spanner, and integrated pressure gauges to monitor when cartridges need replacement.

What makes the SPECTRUM Aqualyze Triple System a reliable choice for high-volume water filtration?

The SPECTRUM Aqualyze Triple System features three large 10-inch cartridges, providing high-capacity and efficient contaminant removal, making it ideal for demanding applications. Its durable polypropylene construction and consistent flow rate up to 25 liters per minute ensure reliable, high-performance filtration.

How easy is it to install the SPECTRUM Economic Three Stage Housing System 10inch?

This filtration system includes a complete adaptor kit, designed for quick and straightforward installation. Its 1-inch port size and compatibility with various end caps like AA, DOE, and CG make setup flexible and hassle-free.

What are the key features of the SPECTRUM Aqualyze Triple System in terms of durability and materials?

Constructed from FDA-compliant polypropylene, the SPECTRUM Aqualyze Triple System is lightweight yet highly durable. It withstands temperatures up to 42°C and pressure of up to 7.0 bars, ensuring long-lasting performance in challenging environments.

Can the SPECTRUM Triple System handle different types of water contaminants?

Yes, with its triple-cartridge setup and compatibility with various filter cartridges, the system is effective at removing bulk solids, sediment, and fine contaminants, making it suitable for a wide range of water purification needs.

What are the specifications and compatibility features of the SPECTRUM Aqualyze Triple System?

The system features three 10-inch by 4.5-inch polypropylene housings, a 1-inch port size, Buna seals, and end-cap compatibility with AA, DOE, and CG types. It supports a flow rate of up to 25 liters per minute and operates efficiently under pressure up to 7.0 bars.

What are the main benefits of the SPECTRUM Aqualyze Double System 10" for my water filtration needs?

The SPECTRUM Aqualyze Double System 10" offers efficient dual-stage filtration in a compact design, making it ideal for spaces with limited room. Its durable polypropylene construction and flexible end-cap compatibility ensure reliable performance and easy integration into various setups.

How easy is it to install the SFHS-2-10SD water filtration system?

The system comes with a complete adaptor kit and features a 1/2-inch port size with Buna seals, making installation straightforward and leak-proof. Its user-friendly design allows for quick connection to existing plumbing systems without any hassle.

Can I use different types of cartridges with this filtration system?

Yes, the SFHS-2-10SD supports AA, DOE, and CG end caps, providing compatibility with a variety of filter cartridges to meet your specific water purification needs.

What are the specifications of the SFHS-2-10SD system in terms of flow rate and pressure?

This water filtration system delivers a steady flow rate of 25 liters per minute and can operate under a maximum pressure of 7.0 bar, ensuring consistent water flow and reliable performance in different conditions.

Is the SFHS-2-10SD suitable for residential or industrial applications?

Designed for smaller-scale commercial, industrial, and residential applications, the SFHS-2-10SD combines high-quality filtration performance with a compact footprint, making it versatile for various settings.

What are the main benefits of the SPECTRUM Aqualyze Double System for water filtration?

The SPECTRUM Aqualyze Double System offers dual-stage filtration with two large 10-inch cartridges, providing efficient and reliable removal of contaminants. Built with durable polypropylene, it ensures long-lasting performance for residential and commercial water filtration needs.

How easy is it to install the SPECTRUM Aqualyze Double System?

The system comes with a complete adaptor kit, including 22mm and 28mm fittings, making installation quick and hassle-free. Its 1-inch port size and Buna seals ensure a leak-free setup and compatible integration with various plumbing setups.

What types of cartridges are compatible with this double system?

The SPECTRUM Aqualyze Double System supports AA, DOE, and CG end caps, allowing you to choose and customize your filtration cartridges based on your specific water purification requirements.

What are the technical specifications of the SFHS-2-10LD system?

Made from FDA-compliant polypropylene, it features two 10-inch x 2.5-inch cartridges, 1-inch port size, Buna seals, a maximum pressure of 7.0 bar, and a temperature capacity of up to 42°C, with a flow rate of 25 liters per minute.

Is the SPECTRUM Aqualyze Double System suitable for high-capacity applications?

Yes, this system is ideal for high-capacity applications in residential, commercial, and light industrial settings, providing efficient cleaning and long-term performance with its robust design and dual-cartridge setup.

SFHS-2-10LD : SPECTRUM Aqualyze Double System Large Diameter 10" with Complete Adaptor Kit

Name: SFHS-2-10LD : SPECTRUM Aqualyze Double System Large Diameter 10" with Complete Adaptor Kit
Brand: SPECTRUM
SKU: 110260 | SFHS-2-10LD
Price: 245.7 GBP
Availability: InStock

SKU: 110260 | SFHS-2-10LD

£245.70

Shipping calculated at checkout.

Technical Resources

Questions & Answers loading...

SFHS-2-10LD: SPECTRUM Aqualyze Double System Large Diameter 10"

Efficient Filtration with Dual-Stage Precision

The SPECTRUM Aqualyze Double System (SFHS-2-10LD) combines durability with high-performance filtration to meet your clean water needs. Designed with a dual-housing setup and large-diameter cartridges, this system offers optimal contaminant removal and enhanced efficiency for both commercial and residential applications. Its complete adaptor kit ensures seamless installation for diverse setups.

Key Benefits at a Glance

Dual-Stage Performance: Two-cartridge system for efficient and reliable contaminant removal.
Durable and Long-Lasting: Built with polypropylene to withstand demanding conditions.
Flexible Installation: Includes a complete adaptor kit for quick and easy setup.
Versatile End-Cap Compatibility: Works with AA, DOE, and CG end caps for enhanced flexibility.
Optimized Flow: Consistent output with a flow rate of 25 liters per minute.

Product Features

Engineered for Dual-Stage Filtration

The SFHS-2-10LD houses two 10-inch cartridges with a 4.5-inch diameter, providing a balanced design that supports pre-filtration and thorough contaminant removal. This setup reduces sediment buildup, prolonging cartridge life and ensuring better water quality.

Built to Last

Manufactured from FDA-compliant polypropylene, this system offers reliable durability for long-lasting use. With a maximum pressure rating of 7.0 bar and a temperature capacity of up to 42°C, it delivers unwavering performance under challenging conditions.

Seamless Integration

Equipped with a 1-inch port size and Buna seals, the SFHS-2-10LD ensures leak-free functionality. The included complete adaptor kit simplifies the installation process, making it an ideal choice for a wide range of systems and applications.

Flexible End-Cap Options

This filtration system supports AA, DOE, and CG end caps, enabling you to choose the cartridge type best suited for your filtration requirements.

Ideal for High-Capacity Applications

Perfect for residential, commercial, and light industrial settings, the SFHS-2-10LD provides an efficient solution for clean water with its versatile and high-capacity design.

Specifications at a Glance

Feature	Specification
Material	Polypropylene
Configuration	2 Cartridges (10" x 4.5")
Port Size	1"
Seal	Buna
Temperature Rating	Up to 42°C
Max Pressure	7.0 bar
Flow Rate	25 liters per minute
End-Cap Compatibility	AA / DOE / CG
Adaptor Kit	22mm, 28mm

What's Included

Two durable housings for large-diameter cartridges (10" each).
A complete adaptor kit for fast and effortless setup.
Compatibility with a variety of filter cartridges for tailored applications.

Choose Water Quality You Can Trust

Upgrade to the SPECTRUM Aqualyze Double System (SFHS-2-10LD) for efficient, high-capacity water filtration. Its user-friendly design, robust materials, and exceptional performance make it the perfect choice for delivering clean and purified water. Invest in better water today.
