SPECTRUM Economic Bag Filter Nylon
SPECTRUM Economic Bag Filter Nylon
SPECTRUM Economic Bag Filter - Traditional High Dirt Holding Bag
The SPECTRUM Economic Bag Filter is a versatile and cost-efficient solution designed for high dirt-holding capacities. Using a traditional single-layer manufacturing method, these filters are reliable for diverse bulk solid removal applications. The all-welded seam construction ensures durability while maintaining filter integrity, even when holding heavy loads.
Designed for Simplicity and Performance
Featuring a single fabric handle across the diameter of the neck, the filter is easy to remove while avoiding contact with unwanted filtrate. Multiple material and micron size options make this bag filter adaptable to a variety of industries and processes.
Features & Benefits
- Robust Design - Heavy-duty double stitching prevents particles from passing through the filter bag.
- Ease of Use - Fabric handle ensures easy removal during change-outs.
- Broad Compatibility - Available in various materials, sizes, and micron ratings.
- Sustainability Option - Polypropylene neck ring allows for recycling or disposal through incineration.
- Enhanced Durability - Optional stainless steel rings ensure strength for demanding applications.
Materials of Construction
-
Neck Material Options:
- Polypropylene
- Stainless Steel (ES)
-
Bag Material Options:
- Polypropylene Felt (P): Featuring a glazed surface finish to prevent fiber migration and broad chemical compatibility.
- Polyester Felt (E): Ideal for high-temperature solvents with excellent durability.
- Nylon Mesh (N): Washable, reusable monofilament mesh for high-strength applications.
- FDA-Compliant Materials
Applications & Industries
Nylon Mesh
- Degreasing processes
- Coolant filtration
- Coarse filtration
- Paints and inks
- Trap filters
- Coatings and varnishes
Felt (Polypropylene or Polyester)
- Pre-filtration in water treatment processes
- Paint filtration
- Syrup production
- Recycled water filtration
- Bulk chemical transfer
- Trap filters
Technical Data
| Specification | Details |
|---|---|
| Efficiency (%) | 70 |
| Maximum Operating Pressure | 1 bar @ 20°C |
| Maximum Operating Temperature | Polypropylene - 95°C, Polyester - 150°C, Nylon - 160°C |
| Bag Sizes | 3, 4, 1, 2 |
| Dimensions (Bag Size 3) | A = 102 mm, B = 229 mm, Area = 0.07 m² |
| Dimensions (Bag Size 4) | A = 102 mm, B = 356 mm, Area = 0.12 m² |
| Dimensions (Bag Size 1) | A = 178 mm, B = 406 mm, Area = 0.23 m² |
| Dimensions (Bag Size 2) | A = 178 mm, B = 813 mm, Area = 0.41 m² |
Product Specification
- Flow Rate: Optimized for water filtration at 20°C using a 25µm Polypropylene Bag.
Ordering Guide
Customize the filter based on the structure below:
- Code: EB
- Neck Style: E, S, P, or ES
- Bag Media: Polypropylene (P), Polyester (E), Nylon (N)
- Micron Ratings: 1, 5, 10, 25, 50, 100, 200
- Bag Size: 1, 2, 3, or 4
Example order: EBSP-5-2 (5-micron polypropylene bag, size 2 with standard neck).
Optimize Your Filtration Process
Choose the SPECTRUM Economic Bag Filter for its versatility, durability, and customizable options. Perfect for industrial filtration needs, it offers high dirt-holding capacity and reliable performance for the most demanding applications.
